M9.8B

PORTABLE

I’ve been eyeing up the Tohatsu 9.8 to replace the Yam 8 i have, The only area I can find of significant difference is the size of the engine, the Tohatsu is not quite such a compact design with a slightly larger box at the top. Unmatched in its class, the Tohatsu 9.8 hp 4-stroke has set the standard in portable outboard power! This lightweight motor weighs in at barely over the 80 lb mark and has undeniable characteristics of a true marine champion. Our 9.8hp outboard is skinny on fuel and big on power while never compromising performance or reliability. Removable Mount for Tohatsu 9.8 HP -Out 26S came with the 8 HP Honda in the next picture. Here is a view from the cockpit and it shows the other mods done to the new motor to make it easier for Ruth and/or I to control it while also manning the rudder tiller.

Tohatsu gives boaters exactly what they need in mid-range portables: more power and less weight! All of these truly portable models offer an incredible horsepower-to-weight ratio, led by the Tohatsu 9.8 2-stroke at just over 26 kgs. Whatever your boating application, these are the ultimate outboards for convenience, reliability and portability.

Tohatsu 2-stroke benefits

Excellent reliability with proven 2-stroke technology
Simple in design

Easy operation and handling

Loop charged induction for smooth operation and fuel economy
CD ignition system for quicker starts

Fundamentals for user convenience and reliability

Through-the-prop exhaust for a quiet ride
Thermostatically controlled cooling system for consistent engine temperature
Stainless steel water pump housing for outstanding durability
High grade marine aluminum alloy that provides the ultimate protection against corrosion
Zinc coating on internal water passages for superior corrosion resistance
Aluminum propeller

Protection

Safety lanyard (an essential protection feature standard on all Tohatsu outboards)
Start-in-gear protection for safer engine starting

SPECIFICATIONS

Engine	Two Stroke 2 Cylinder
Output	9.8 ps (7.2 kw)
Displacement	169 cc (10.31 cu.in.)
Bore x Stroke	50 x 43 mm (1.97 x 1.69 in)
Starting	Electric or Manual
Control Type	Tiller Handle
Gear Shift	Forward - Neutral - Reverse
Gear Ratio	2.08:1 (13:27)
Ignition System	ATDC1゜- BTDC17゜
Propeller Selection Range	5' - 9.5'
Transom Height	15', 20', 25'
Fuel	Unleaded Gasoline (87 Octane)
Oil Type	Genuine recommended 2stroke engine oil (TCW-3)
Fuel Tank	12 L (3.17 US Gal.) Separate Fuel Tank
Weight*	26.0 Kg (57 lbs.)
Alternator Output	Optional: 12V, 80W, 7A (Standard on Electric Start Models)
Max. RPM Range	5,000 - 6,000
Start In Gear Protection	Standard
Thermostat Controlled Cooling System	Standard
Through-The-Prop Exhaust	Standard
Shallow Water Drive	Standard
Engine lubrication system	Premixed Fuel

* Weight specification is based on the lightest version.
Specifications and descriptions are subject to change without notice.

Model	Shaft Length	Cylinders	Electric Start	Tiller Handle	12V Charging System	Remote Fuel Tank	Propeller
M9.8BS	15'	2	S	S	S
M9.8BL	20'	2	S	S	S
M9.8BUL	25'	2	S	S	S
M9.8BEFS	15'	2	S	S	S	S	S
M9.8BEFL	20'	2	S	S	S	S	S

Specifications subject to change without notice. Additional models and/or configurations may be available. Contact your local dealer for details.
